Ultrasonic Fuel Sensor (For Diesel, Petrol & Palm Oil)

Capacitance fuel level sensor is used to continuously detect fuel level by measuring the capacitance variations as the liquid level changes, which can be easily shortened to fit the different tank depths. The Sensor is connected to Comcentric GPS & Communication Unit to provide real-time fuel level monitoring and fuel theft alarms.

Shell Chemicals
Commercial Fuels
  • Suitable for Vehicle, truck, coach, generator set, construction machinery and more…
  • Signal output with high-resolution :1mm
  • Continuous and steady output signal
  • Length could be trimmed in the field The parameters can be conveniently reset and recalibrated with a calibrator
  • Fits different tank sizes, minimizing customer inventory level
  • Used for diesel, gasoline and kerosene level measuring
  • Material: Plastic and Aluminium Alloy
  • Length range: 200-1500mm
  • Supply voltages: 10 to 32V
  • Rated current for alarm switch: 500mA
  • Output signal:RS232, RS485
  • Resolution: 1mm
  • Operating temperatures: - 40 to 85°C
  • Protection rank: IP65
